NSR 6710 Formula 22 10T Inline Pinion, 5.5mm

$6.99
SKU: NSR 6710
U/M: Pkg. of 2

The NSR 6710 is a 10-tooth inline pinion for the NSR Formula 22 drivetrain.

NSR part number: 6710
Also listed as: NSR6710 or NSR 6710

Specifications

Specification Details
Tooth count 10
Outside diameter 5.5 mm
Motor shaft diameter 2.0 mm
Pinion family NSR 67xx - 6709, 6710, 6711
Crown Gear Family NSR Inline - 6324BZ, 6325BZ, 6326BZ, 6327BZ
NSR Inline EVO3 - 6324AL-EVO3, 6325AL-EVO3, 6326AL-EVO3, 6327AL-EVO3
Material Brass
Motor configuration Inline
Design Formula 22-specific inline pinion

Compatibility and Fitment

Pinion family and Crown gear family part numbers shown in the table above are for NSR cars. If you plan to use NSR gears for other brands/applications, you may have to use different combinations of gear sets (check before purchasing). Confirm motor-mount spacing and gear mesh. Use a suitable pinion puller/press to prevent motor-shaft damage during installation and removal. This Formula 22 design requires the NSR 4105 Formula 22 Pinion Puller; a conventional puller is not suitable.

Package Contents

Two (2) pinions.
